EPSON CB-L500W
-
Lumens: 5000 lumens
-
Standard Resolution: WXGA（1280*800）
-
Display Chip: three × 0.59 inch chip
-
Display Technology: 3LCD
-
CPU:
-
RAM:
-
Storage:
Media Reviews
Epson CB-L500W is a laser projector that features a 20,000-hour long-life light source, optical components optimized for high brightness and compactness, custom brightness, and constant output.
In terms of optical components, unlike traditional laser diode light emitting plates, Epson CB-L500W uses a compact laser diode collection plate to output the same energy while reducing the projector’s size, matching the original reflective fluorescent wheel to effectively reduce light energy loss and achieve compactness and high brightness.
EPSON CB-L500W - Specs
Optical Parameters
| Brand Brand | Epson |
| Brand Model Brand Model | epson CB-L500W |
| Brightness (ANSI lumens) Brightness (ANSI lumens) | 5000 lumens |
| Display Chip Display Chip | three × 0.59 inch chip |
| Display Technology Display Technology | 3LCD |
| Standard Resolution Standard Resolution | WXGA（1280*800） |
| Image Contrast Ratio Image Contrast Ratio | 2500000:1 |
| Throw Ratio Throw Ratio | 1.38-2.24 |
| Keystone Correction Keystone Correction |
Horizontal: ± 30 degrees Vertical: ± 30 degrees |
| Lamp Life Lamp Life | Normal mode: 20000 hours, economic mode: 30000 hours |
| Lamp Type Lamp Type | laser |
| Focus technology Focus technology | Manual focus |
Projection Parameters
| Image Size Image Size,projector1 | 29-280 inches |
| Screen ratio Screen ratio | 16:10 |
| Projection method Projection method | Forward projection, rear projection, table, ceiling |
Ports
| I/O Connection Ports Connection Ports |
two × HDMI (hdmi2 supports MHL) one × Video input: RCA one × Audio input: RCA two × Video input: D-sub 15 pin two × Audio input: stereo mini one × Microphone input |
Other
| Size(HxWxD) Size(HxWxD) | four hundred and forty × one hundred and forty × 349mm |
| Power Usage Power Usage | Normal mode: 322W, economic mode: 244w, standby power: 0.3w |
| Noise Level Noise Level | Normal mode: 37db, economic mode: 25dB |
| Machine weight Machine weight | 7.4kg |
| Accessories Accessories |
Power cord (3m) x1 Vag cable (1.8m) x1 Remote control x1 Battery (AA) x2 User manual (CD-ROM) x1 |
| Warranty Warranty | 2 years |
| other other |
Adjustment function: color mode (dynamic, presentation, cinema, sRGB, DICOM SIM, multi picture projection) Gamma custom adjustment (gamma curve 9-point adjustment) Rgbcmy correction (hue, saturation and brightness of rgbcmy are adjustable) Easy to use functions: fast four corner adjustment, arc correction, split screen projection, split screen projection, schedule setting Advanced presentation management: Epson iprojection, Epson projector management, Epson projector content manager |
